Welcome to SAWSAT website!
GaN/Si Lumped-Element SAW Duplexers for Satellite Telecommunications above 7 GHz

Project type: Experimental Demonstrative Project
Project duration: 23.10.2020-22.10.2022
Project budget: 584.950 RON
Domain project: INFORMATION AND COMMUNICATION TECHNOLOGIES, SPACE AND SECURITY

Project sumary

The scope of the project is the development of a new class of monolithic integrated duplexer circuits, based on two GaN/Si Surface Acoustic Wave (SAW) band pass filters (BPF) operating in the satellite communication bands (7.25 – 7.75 GHz) and (7.9 – 8.4 GHz) and a phase compensation network.

The BPFs will be based on SAW resonators integrated with series and parallel connected planar inductors with operating frequency above 7 GHz. The targeted duplexer performances (insertion losses in the range 6 – 12 dB, out-of-band rejection better than 25 dB and isolation between Tx and Rx higher than 40 dB) are well beyond the current state of the art for SAW duplexers. The SAW resonant frequencies will be pushed above 7 GHz by innovative technological development for digit widths below 100 nm, different interdigital transducer metallization, GaN layer thicknesses and superstrate layers. Multiphysics simulations will be used for the piezo-electro-mechanical modeling and analysis of the piezoelectric device and different acoustic propagation modes investigations.

Full wave 3D electromagnetic (EM) simulation software will be used for advanced EM modeling of the BPFs and duplexer layouts. The optimization of the duplexer design will be performed at circuit level and will include a phase compensation network. The characterization of the SAW duplexer demonstrator will include microphysical techniques (SEM, AFM), on wafer scattering (S) parameter measurements, measurements in the – 55°C …+125°C temperature range and high-power nonlinear effects assessment.

The project will start at TRL 2 (“Technology concept and/or application formulated”), with some preliminary simulation results presented in the proposal. The duplexer circuits will be tested on-wafer in laboratory environment and the main parameters will be compared to specifications, thus taking the proposed technology to TRL4 (“Component and/or Breadboard Functional Validation in Laboratory Environment”).

News

Results 2022

Results

Results 2021; Results 2020




Financing agency: Executive Agency for Higher Education, Research, Development and Innovation Funding – UEFISCDI (www.uefiscdi.gov.ro)

PN III, Programme 2 – Increasing the competitivity of the Romanian economy through research, development and innovation; Subprogramme 2.1. Competitivity through research, development and innovation, Project type: Experimental Demonstrative Project
Contract no. PED 422/23.10.2020 (code: PN-III-P2-2.1-PED-2019-2041)



Coordinating Institution: National Institute for Research and Development in Microtechnologies – IMT Bucharest (www.imt.ro)
Project Leader: Dr. Alina-Cristina BUNEA
